Fantech SHR 1505R - Installation Examples; Fully Dedicated System

5
fantech
Installation examples
FULLY DEDICATED SYSTEM
BEST FOR NEW CONSTRUCTION
Stale air is drawn from key areas of home (bathroom, kitchen, laundry)
Fresh air supplied to main living areas
1. Furnace blower must operate when ventilation from HRV is required. The
furnace should be set to run continuously or interlocked with HRV.

minimum separation and 460 mm (18") above grade is recommended.


procedure found in section “AIRFLOW BALANCING”.
Suggested installation for:
Hydronic baseboard
Inoor heating
Electric baseboard

Benets: Provides the best
fresh air distribution in the
house; lowest operation cost
since the furnace/air handler
unit is not needed.
Air from inside

furnace blower is running.
* Ductwork layout may dif-
fer depending on model
Stale air to
outside
Fresh air from
outside
Fresh air to
living areas
