MAIN PARTS
17
18. Front brake fluid tank
(“Competition” version)
19. Front brake fluid tank
(“Performance” version)
20. Kick starter
21. Coolant radiator cap
22. Front brake lever
23. Throttle control
24. Rear brake fluid tank
25. Right footrest
26. Gear oil drain plug
27. Rear brake pedal
28. Gear oil level plug
29. Gear oil fi ller cap
30. Spark plug
31. Coolant radiator
18 19
23
24 25 26 27
28
29
30
31
22
2120
