88
MAINTENANCE
REAR VIEW MIRRORS
The operations described below are valid for both rear-
view mirrors.
Place the vehicle on the stand and on a flat and stable
surface. Loosen the lock nut “A”, turn the mirror counter
clockwise and remove it.
During reassembly, before tightening the nut, check that
the mirror support rod is aligned with the handlebar.
Rear view mirrors adjustment
To adjust the rear-view mirrors, steer onto the vehicle in
running position and rotate the mirror according to your
needs. It is also possible to adjust the inclination of the rear-
view mirror support rod. To do this, loosen the screw “B”
and move the support rod sideways. Make the adjustment
and tighten the screw “B”.
B
A
