83
MAINTENANCE
IT
EN
DE
FR
THROTTLE CONTROL
For the maintenance intervals, see (PERIODIC MAINTENANCE
CHARTS), under:
– Throttle control.
Check
The no-load travel (A) of the accelerator handle must be 2–3
mm, measured on the rim of the actual twist grip handle.
Adjustment
– Place the vehicle on the stand.
– Remove the protective sleeve (1).
– Loosen the ring nut (2).
– Turn the adjusting device (3) to reset the recommended
value.
After the adjustment:
– Manually lock the adjuster rotation (3) and tighten the ring
nut (2).
– Check the no-load stroke (A).
If the outcome is positive:
– Replace the protective sleeve.
After having completed adjustment, check that the
engine idle speed does not change upon turning the
handlebar and that when the accelerator handle is
released it returns automatically to the rest position.
2 3 1
A
