Step
Procedure
6
Remove the outer back cover. Remove the 2 screws at the base of the back cover.
Lift UP the bottom of this cover to release the upper tabs that hold the cover to the frame.
7
Remove the Front Cover by bending from the center.
8
Procedure is complete.
