9.2 LOADING THE CUPS
Use only vending machine cups with an outer edge diameter of 70 mm or 73mm. To adjust the cup holder
diameter on the dispenser move the lever "A" as shown in the figure.
To prevent the vending machine from malfunctioning, before loading the cups check that they are not
damaged or squashed into each other.
Turn off the vending machine by removing the key from the door safety switch, remove the cover from the
cup holder and start by inserting the cups in the column immediately to the left of the cup dispenser outlet,
and proceed in a counter clockwise direction.
Insert the key in the door safety switch and the cup holder rotation ratiomotor will rotate until the cups are
correctly positioned in the dispensing seat.
If using cups with a 73 mm diameter, remove the reducers "C" inserted in the cup chute.
Use only vending machine cups with an outer edge diameter of 70 mm or 73mm. To
adjust the cup holder diameter on the dispenser move the lever "A" as shown in the
figure.
To prevent the vending machine from malfunctioning, before loading the cups check
that they are not damaged or squashed into each other.
If using cups with a 73 mm diameter, slide the cup chute out from the back by pressing
the two levers "B" and remove the reducers "C" inserted in the cup chute.
