Fastech Ezi-SPEED ESD-30-C User Manual

-89-
• Pin plan of motor cable
It is the pin plan of motor cable from motor side
- Pin plan of motor connector
No
Color
Function
Pin plan
1
-
-
Purpose
ITEM
Specification
Manufacturer
Motor side
Housing
5557-04R
MOLEX
Motor side
Terminal
5556T
MOLEX
2
BLUE
BLDC_U
3
GRAY
BLDC_W
4
PURPLE
BLDC_V
- Pin plan of sensor connector
No
Color
Function
Pin plan
1
YELLOW
+5V_E
Purpose
ITEM
Specification
Manufacturer
Motor side
Housing
5557-06R
MOLEX
Motor side
Terminal
5556T
MOLEX
2
BLOCK
Shield
3
GREEN
GND_E
4
BROWN
HALL_U
5
WHITE
HALL_V
6
ORANGE
HALL_W
• Pin plan of I/O signal connector
No
Color
I/O
Pin plan
1
HCOM
Common
Purpose
ITEM
Specification
Manufacturer
Controller side
Housing
15EDGKD-13P
DEGSON
2
X0
Input
3
X1
Input
4
X2
Input
5
X3
Input
6
X4
Input
7
LCOM
Common
8
Y0+
Output
9
Y0-
Output
10
Y1+
Output
11
Y1-
Output
12
Y2+
Output
13
Y2-
Output
1
1
2
2
3
3
4
4
5
6
1
13
