[tq.LM]
Torque limit
It is output when the torque limit is reached.
[MovE]
Motor operation
It is output when motor is operated.
[vA]
Rotation speed att
ainment output
It is output when the motor rotation speed becomes equal the
value set by the rotation speed attainment band parameter.
[WnG]
Warning output
It is output when a warning generates. (The motor will continue to
operate.) when the warning is released, it will automatically turn
OFF
[----]
Not used
This input is not assigned to any signal.
8.4 Display on the drive
• Operation Mode : Monitor mode
Item
Display
Description
Setting rotation speed
display and speed
adjustment[RPM]
100
It is displayed motor rotation speed.
Actual rotation
speed[rpm]
0
• Monitors the rotation speed of gearhead.
• Monitors the rotation speed of the gear output shaft or
conveyor speed when the “speed reduction ratio”
parameter is set.
• When the “speed inceasing ratio” parameter is set, the
rotation speed being increased by the external mechanism
is displayed.
Load factor[%]
L. 0
The motor generating torque can be checked. The present
load factor is displayed based on the rated torque being
100%.
The display is the load factor on the motor output shaft. It
is not for the gearhead output shaft. With combination
type product, the permissible torque varies depending on
the gear ratio of the gearhead. Use the product so that the
load does not exceed the permissible torque of the
gearhead output shaft.
Alarm record and reset
AL.rc
Display alarm record. You can check and reset alarm record.
