7 / 92FAVERO ELECTRONICS - 0259-1060 - FA-15 User Manual - Rev03
ENGLISH
1.5. Rear layout of the FA-15 (connections)
The back of the device is dedicated to connections, composed of the following:
321
5 56
47
1
1. Holes for attaching wall brackets (VESA
100X100 compatible)
2. Power bank zone
3. USB power cable
4. Outputs for repetition of display
5. Weapon connections
6. Piste connection
7. Input for connection of another MASTER
device.
Fig. 2
Rear view (connections).
