8 / 92 0259-1060 - FA-15 User Manual - Rev03 - FAVERO ELECTRONICS
ENGLISH
1.6. Remote control
The FA-15 device is managed entirely via infrared remote control, included as standard. This is equipped
with a membrane keyboard and is powered by a rechargeable Li-ion internal battery. The operating
distance of the remote control is over 20 m. The remote control is composed as follows:
5
6
4
2 1
1 2 3
1. Transmission LED: indicates button
presses
2. Battery status LED:
• on during charging
• off when charging is complete or
with charger disconnected
3. Membrane keyboard
4. Input for micro-USB connector for
battery charging
5. Infrared transmitter
6. Connector CURRENTLY UNUSED
Fig. 3
Remote control
1.7. Remote control/App functionality
Note
The functions of the keys on the remote control and those represented in the app (under
remote-control function) are the same.
Some keys have a dual function. The second function is activated by pressing and holding the
[ALT] key and then simultaneously pressing the desired key.
