EN-23
| evation
4.1.3 Removing the drivepack from the e-bike
More detailed information can be found → in chapter 15.2 “Removing the drivepack
from the e-bike”.
1. Secure the drivepack with one hand.
2. Press the push button and move the locking lever upwards as far as
possible to release the drivepack from the lock.
3. Hold down the push button and carefully lower the drivepack. The
locking lever automatically remains in the open position.
4. Remove the drivepack from the interface of the bottom bracket.
4.1.4 Removing the battery from the drivepack
More detailed information can be found → in chapter 31.3 “Removing the battery from
the drivepack”.
1. Secure the battery with one hand.
2. Press the push button as far as it will go to release the battery from
the lock.
3. Press and hold the push button and gently pull the battery out of the
battery holder.
