24 DETAILED VIEW & PART DESIGNATIONS: REMOTE fX
AND REMOTE bX

Remote fX and Remote bX are different in terms of where
they are attached:
→
Remote fX is located on the frame (top or bottom tube),
→ Remote bX is located on the handlebars.
Remote fX
Remote bX
C
2
1
3
4
5
Remote bX
2
1
3
4
5
Remote fX
C
5
6
7
