EN-43
| evation
2. Swing the upper end of the drivepack into the downtube of the e-bike.
When you have inserted the drivepack correctly and completely into
the downtube, the locking mechanism built into the downtube auto-
matically engages in the motor mount and locks the drivepack in the
correct position (audible click).
The push button or locking lever also moves automatically into the
closed position.
3. Check the drivepack is securely in position.
If the drivepack does not lock, pull it out again if necessary and then try
to insert it again. Do not use the drive system if the drivepack cannot
be locked to the e-bike.
