Part designations
1
→
Top button
2
→
Centre button
3
→
Bottom button
4
→
LED display
5
→
Status display
6
→
Display of charging level/support level
7
→
Remote fixing screw
The numbering 1 – 7 within this section refers to the indi-
vidual parts of the component
C
(Remote b).
Individual parts of other components illustrated within this
section are additionally marked with the corresponding
component letter.
