Manual VEK MNE1 / VEK MNE2
FEIG ELECTRONIC GmbH 09/2015 9
GBR
7 Installation Instructions
7.1 Installation Location
Traffic detector VEK MNEx shall be installed into a switchboard or switchboard-like enclosure. The choice of
the installation location must be such that the operation of the traffic detector cannot be impaired by humidity,
dust or dripping water.
7.2 Pin Assignment
The table below shows the different pin assignments of the 11-pin round plug for the different pin-outs –A .. –
G.
Pins on 11-pin round plug
Pin as-
signment
1 2 3 4 5 6 7 8 9 10 11
-A
L/24V
N/GND
NO2 COM2 NC1 COM1 L1a L1b - NO1 NC2
-B
NO2 - COM1 NO1 L1a L1b COM2 NC1 NC2
-C
NC2 COM2 NC1 COM1 L1a L1b - L2a L2b
-D
NO2 COM2 NO1 COM1 L1a L-Com L2a NC1 NC2
-E
L1a L1b L2a L2b NO2 COM2 NC2 NO1 COM1
-F
L1a L1b L2a L2b NC2 COM2 - NC1 COM1
-G
*
COM1+2 NO1 NC1 (L2a) (L2b) L1a L1b (NO2) L/24 V (NC2)
L / 24V -R230: L
-R24: 10-30 V AC/DC
N / GND -R230: N
-R24: GND
L1a, L1b Inductive loop terminal channel 1
L2a, L2b Inductive loop terminal channel 2
L-Com common terminal Inductive loop channels 1 and 2, special assignment
NO1, NO2 normally open contact Output 1 or output 2
NC1, NC2 normally closed contact Output 1 or output 2
COM1, COM2 common contact Output 1 or output 2
COM1+2 common terminal for a common contact output 1 and 2, special assignment
In addition, the inversion settings of relay contacts may need to be observed!
I.e. normally open contacts may be represented as normally closed contacts and vice versa.
On the units of the version R230, all connecting cables of the 11-pin round plug must be rated at 240V. I.e.,
normally open contacts may be represented as normally closed contacts and vice versa.
When extra low voltage (e.g. 24 V DC) and low voltage (e.g. 230 V AC) are being used, it is not permitted to
mix the operation of the two outputs !
*
