VEK MNH1-R24-A
VEK MNH1-R24-A GUIDE DE DÉMARRAGE RAPIDE 1.4 FR
4 | 4
SENSORS
Les variantes canal 1 possèdent un interrupteur DIP 8 pôles destiné à la
configuration du détecteur.
DIP
Désignation
Fonction
1
Sense a
Sensibilité boucle 1
2
Sense b
Sensibilité boucle 1
3
Frequency
Niveau de fréquence
4
Hold Time
Temps d’arrêt jusqu’au réajustement
5
Output 2
Mode signal de sortie 2
6
Edge 2
Moment signal de sortie 2
7
Inv. Out 1
Inversion signal de sortie 1
8
Inv. Out 2
Inversion signal de sortie 2
Tab. 8: Occupation interrupteur DIP (par défaut)
Les paramètres suivants peuvent être réglés à l’aide des interrupteurs
DIP :
Interrupteur DIP
Position
Valeur
Sense a
ON
0,01 % (haut)
Sense b
ON
Sense a
OFF
0,01 % (haut)
Sense b
ON
Sense a
ON
0,16%
Sense b
OFF
Sense a
OFF
0,64 % (bas)
Sense b
OFF
Frequency
OFF
low (bas)
ON
high (élevé)
Hold Time
OFF
5 minutes
ON
illimité
Output 2
OFF
Signal d’impulsion
ON
Signal continu
Edge 2
OFF
Moment de traverser
ON
Moment de quitter
Inv. Out 1
OFF
inversé
ON
non inversé
Inv. Out 2
OFF
non inversé
ON
inversé
Tab. 9: Réglages par interrupteur DIP (1 canal)
4.4 Port USB
La configuration détaillée et le diagnostic des données du détecteur sont
possibles via l'interface USB.
Le programme de service gratuit Detector Tool peut être téléchargé à
partir de l'espace client sur www.feig.de. De plus, un ordinateur et un
câble USB de type Mini-AB sont nécessaires.
