SENSORS
The following parameters can be adjusted with the DIP switch:
DIP switch
Position
Value
Sense a
ON
0.01% (high)
Sense b
ON
Sense a
OFF
0,04%
Sense b
ON
Sense a
ON
0,16%
Sense b
OFF
Sense a
OFF
0.64% (low)
Sense b
OFF
Frequency
OFF
low
ON
high
Hold time
OFF
5 minutes
ON
infinite
Output 2
OFF
Pulse signal
ON
Continuous signal
Edge 2
OFF
on entering
ON
on leaving
Inv. Out 1
OFF
inverted
ON
not inverted
Inv. Out 2
OFF
not inverted
ON
inverted
Tab. 9: Settings via DIP switch (single-channel)
4.4 USB interface
Detailed configuration and diagnosis of the detector data are possible via
the USB interface.
The free Detector Tool service program can be downloaded from the
customer area at www.feig.de. In addition, a computer and a USB cable
of the Mini-AB type are required.
