Bandsaw
FB 540/640/740/840/940
4 Specifications
4.1 Dimensions and weight
4.2 Operation and storage conditions
Operation/room temperature +10 to +40 °C
Storage temperature –10 to +50 °C
4.3 Electrical connection
The following electrical requirements must be fulfilled:
• Earth the machine using an electrical conductor.
• The voltage regulation in the electricity network must
not exceed ± 10% of the rated voltage.
• The quality of the connection cable has to be of the
4(5)x2.5 H07RN-F type or at least of equivalent
quality.
• The current supply has to be protected against dam-
ages e.g. armoured conduit.
• Connected dust extraction hoses have to be earthed to
avoid electrostatic charges.
Attention! All operations may only be executed by an authorised electrical technician!
Specifications
FB 540 FB 640 FB 740 FB 840 FB 940
Wheel diameter (mm) 540 640 740 840 940
Wheel speed (rpm) 950 810 640 610 520
Motor power: kW (HP) S1 1,5 (2)
1,1 (1,5)
2,2 (3) 3 (4) 4 (5,5) 5,5 (7,5)
Cutting height max.(mm) 350 400 450 540 560
Rip capacity max. (mm) 520 620 720 820 910
Table size (mm) (L x W) 520 x
720
600 x
885
710 x
1100
800 x
1160
800 x
1250
Saw blade length (mm) min. 4190 4730 5340 6000 6610
Saw blade length (mm) max 4270 4800 5420 6110 6710
Total size (mm
(L x W x H)
870 x
520 x
1970
1050 x
620 x
2180
1180 x
720 x
2430
1410 x
820 x
2650
1550 x
920 x
2900
Net weight (kg) 240 350 450 580 700
*) S6 = 10 minute operation under load and intermittent service; 40% = relative operating factor, i.e. the motor may be
run at the nominal capacity for 4 minutes and afterwards must run idle for 6 minutes.
