Felder FB 710 - Specifications; Dimensions and Weight; Electrical Connection;Drive Motor

12
Bandsaw
FB 510/610/710 & FB 710 c-tech
FB 510 / 610 FB 710
Motor voltage 1x 230 V 3x 400 V 3x 230 V 3x 400 V
motor frequency 50/60 Hz 50/60 Hz
System of protection IP 55 IP 55
Motor power S6-40 % – 50 Hz *) 2,5 kW 3,0 kW 5,5 kW 4,0 / 5,5 kW
Motor power S6-40 % – 60 Hz *) 3,0 kW - - kW 5,5 kW 5,5 kW
*) S6 = operation under load and intermittent service; 40% = relative operating factor
The actual values can be found on the data plate.
4.2 Electrical connection/Drive motor
Specifications
4 Specifications
4.1 Dimensions and weight
Machine (L x W x H) FB 510 FB 610 FB 710
Total size (mm) 454 x
829 x
1995
460 x
985 x
2043
490 x
1110 x
2270
Package size (mm) 1200 x
800 x
2200
1200 x
800 x
2250
2365 x
720 x
1222 *)
Net weight (kg) 250 320 400
*) Option (Export) = 1110 x 490 x 2360 mm
Bandsaw FB 510 FB 610 FB 710
Cutting height 410 mm 410 mm 460 mm
Rip capacity max. 480 mm 575 mm 690 mm
- || - Rip fence 323 mm 435 mm 435 mm
Saw blade length 4318 mm 4546 mm 5120 mm
Saw blade width min. 6 mm 6 mm 6 mm
Saw blade width max. 25 mm 30 mm 30 mm
Saw blade speed 24,3 m/sec 23,8 m/sec 20,6 m/sec
Wheel diameter 500 mm 600 mm 710 mm
Table size 500 x 640 mm 560 x 850 mm 700 x 840 mm
Tiltable table –10 max. +45° –5 max. +45° –5 max. +45°
Operation and storage conditions
Operating/room temperature +10 to +40 °C
Storage temperature –10 to +50 °C
