Procedure
1.
Select the RTK Network correction signal
under 'Signal Type'.
2.
Select the modem type "External modem"
3.
Enter the baud rate
4.
Select parity
5.
Select signal format
Fig. 47
Display
Satellite receiver Designation of the installed receiver
Signal type The correction signal source can be selected here
Modem type External modem
Signal strength Mobile communications signal strength
Accuracy Bar indicator and decimal value of static accuracy
Signal lag Specifies the time in s taken to receive the correction signal update. If 999 is
shown here, the correction signal cannot be currently received.
Connection status Specifies the connection status of the GNSS receiver to the source of the
correction data (e.g. connected, update required, expired). The tick shows
whether the GNSS receiver is currently connected to the correction data
source.
Authorisation level Specifies the accuracy level of the GNSS receiver (depending on the hardware
modules installed in the receiver)
Baud rate 9600 / 19200 / 38400 / 57600 / 115200
Parity Invalid/none/even/odd
Signal format CMR/RTCM 2.3/RTCM 3.1
7. Start-up
VarioGuide 99
438.020.070.012
