Racordarea la hornuri colective
fig. 21- Exemple de racordare la hornuri ( = Aer / = Gaze arse)
fig. 22- Exemple de racordare sistemul C10 şi C11 ( = Aer / = Gaze arse)
C 8X C 2X
C 4X
C93C93
C 11
C 11
C 10
C 10
