Ferroli BLUEHELIX MAXIMA Series User Manual

BLUEHELIX MAXIMA
199EN
cod. 3541U630 - Rev. 00 - 07/2020
Table 5- Accessories
Losses in m
eq
Air
intake
Fume exhaust
Vertical Horizontal
Ø 80
PIPE 1 m M/F 041104X0 1.0 1.6 2.0
BEND 45° M/F 041103X0 1.2 1.8
90° M/F 041102X0 1.5 2.0
PIPE SECTION with test point 1KWMA70W 0.3 0.3
TERMINAL air, wall 1KWMA85A 2.0 -
fumes, wall with antiwind 1KWMA86A - 5.0
FLUE Split air/fumes 80/80 010027X0 - 12.0
Fume outlet only Ø80 010026X0 +
1KWMA86U
-4.0
Ø 60
PIPE 1 m M/F 1KWMA89W 6.0
BEND 90° M/F 1KWMA88W 4.5
REDUCER 80/60 041050X0 5.0
TERMINAL fumes, wall with antiwind 1KWMA90A 7.0
Ø 50
PIPE 1 m M/F 041086X0 12
BEND 90° M/F 041085X0 9
REDUCER 80/50 041087X0 10
ATTENTION: CONSIDER THE HIGH PRESSURE LOSSES OF Ø50 and Ø60 ACCESSORIES; USE
THEM ONLY IF NECESSARY AND AT THE LAST FUME EXHAUST SECTION.

Ferroli BLUEHELIX MAXIMA Series Specifications

General

Type	Condensing Boiler
ErP Rating	A
Heat Exchanger Material	Stainless Steel
Modulation Range	1:10
Installation	Wall-mounted
Fuel Type	Natural Gas
NOx Class	Class 6
Hot Water Production	Instantaneous
Efficiency	Up to 98% (ErP)
Warranty	2 years
