Table of faults
Table 8- List of faults
Fault code Fault Possible cause Cure
A01 No burner ignition
No gas
Check the regular gas flow to the boiler and that
the air has been eliminated from the pipes
Ignition/detection electrode
fault
Check the wiring of the electrode and that it is
correctly positioned and free of any deposits;
replace the electrode if necessary.
Faulty gas valve Check the gas valve and replace it if necessary
Insufficient gas supply pres-
sure
Check the gas supply pressure
Trap blocked Check the trap and clean it if necessary
Air/fume ducts obstructed
Remove the obstruction from the flue, fume
extraction ducts, air inlet and terminals.
A02
Flame present signal with bur-
ner off
Electrode fault
Check the ionization electrode wiring
Check the condition of the electrode
Electrode to ground
Cable to ground
Check the trap and clean it if necessary
Card fault Check the card
A05 Fan fault
No 230V power supply
Check the 5-pin connector wiring
Tachometric signal interrupted
Fan damaged Check the fan
A06
No flame after the ignition
phase
Ionization electrode fault Check the position of the ionization electrode
and replace it if necessary
Flame unstable Check the burner
air/fume ducts obstructed
Remove the obstruction from the flue, fume
extraction ducts, air inlet and terminals
Trap blocked Check the trap and clean it if necessary
F03
F15
F18
A07
High fume temperature
The fume probe detects an
excessive temperature
Check the exchanger
Check the flue gas probe
Check the flue material parameter
F04
A08
Overtemperature protection
intervention
Heating sensor damaged
Check the correct positioning and operation of
the heating sensor and replace it if necessary
No water circulation in the sys-
tem
Check the circulating pump
Air in the system Vent the system
F16
A09
Overtemperature protection
intervention
Return sensor damaged
Check the correct positioning and operation of
the return sensor and replace it if necessary
No water circulation in the sys-
tem
Check the circulating pump
Air in the system Vent the system
F19
A10
Flow sensor fault
Sensor damaged
Check the wiring or replace the sensorWiring shorted
Wiring disconnected
F22
A11
Return sensor fault
Sensor damaged
Check the wiring or replace the sensorWiring shorted
Wiring disconnected
F12 DHW sensor fault
Sensor damaged
Check the wiring or replace the sensorWiring shorted
Wiring disconnected
