FERROLI F30
1
4
A 90° bend (fi g. 15) is supplied for the horizontal connection of air and fl ue gas pipes. This can be angled
towards the chosen wall in degrees of 45°.
3.03 Top Outlet Concentric Flue Connection
3.03.1 Vertical concentric connection
1KWMA31Y
DS
L
125
70
50*
30
95
80
80
-3 mm/m
Ø60 Ø80
70 min.
* = between 10 e 60 mm
190 270
F
ig.
1
5
A vertical connector can be supplied for vertical
discharge with concentric pipes.
The simple mounting and use of double lip gaskets
at the joints makes this an extremely easy and safe
option.
Fig.
14
Concentric
Vertical
Connector
3.03.2 Horizontal concentric connection
L = S = D = 255
