Technical specifications
Type CP FB9-E
Protection class (as per DIN 40050) IP 65
Ambient temperature - 5
o
... + 50
o
C
Storage temperature - 20
o
... + 70
o
C
Pin 1 – Operating voltage connection
for electronic components/inputs
• Rated value
(protected against incorrect polarity)
• Tolerance
• Current consumption
DC 24 V
DC 18 V...30 V
200 mA
Pin 2 – Operating voltage connection
for outputs/valves
• Rated value
(protected against incorrect polarity)
• Tolerance
• Current consumption
DC 24 V
DC 20,4 V...26,4 V)
Sum of all switched
CP solenoid valves
Electromagnetic compatibility (EMC)
Resistance to suppression
• tested as per EN 55011
Resistance to interference
• tested as per EN 50082-2
Limit value severity A
