Festo SPC-10 Series User Manual

Summary of fitting and installation of pneumatic components
1
2
3
4
5
6
7
8
Pneumatic linear drive with linear potentiometer
Fixed stops A and B
Potentiometer connection
Work connection 2 (effective in direction away from potentiometer
connection)
Proportional directional control valve
Compressed air connection 1 (5 - 7 bar +/- 1 bar)
Service unit (without lubricator, with 5
µ
m filter)
Work connection 4 (effective in direction towards potentiometer
connection)
1
2
4
5
6
7
8
3
English
SPC-10-...
9902c 15

Festo SPC-10 Series Specifications

General

Brand	Festo
Model	SPC-10 Series
Category	Controller
Language	English
