Fetco Extractor Plus CBS-1251 - Page 21

Go to fetco.com for the latest versions of all information Page 21 User Guide & Operator instructions P213e0 NOVEMBER 2021
REF
QTY
Part number
Description Drawing 1101.00573.00, 1101.00059.00 Parts CBS-1252 and applies to CBS-1253
1
1
1111.00099.00
WELDMENT BODY, CBS-2252 1½ gallon brewer only
1
1
1111.00114.00
WELDMENT BODY, CBS-2252 2 gallon brewer only
2
6
1084.00051.00
NUT, HEX LOCKWASHER, #8-32, 18-8 ST. STL.
3
1
1102.00470.00
FRONT PANEL ASSY, DOUBLE, PLUS SERIES
4
2
1082.00029.00
SCREW, #6 X 3/8 LG, TRUSS HD PHIL, SHEET MTL
5
2
1082.00058.00
SCREW, # 8-32 X 5/8, FLAT HD, PH, 18-8 SS
6 REF
1
Reference
ELECTRICAL COMPONENT LATTICE, NEXT GEN XV+
6-1
1
1023.00350.00
ELECTRICAL MOUNTING LATTICE, COMMON
6-2
1
1052.00023.00
EUROSTRIP HE16 TERM. BLOCK, 4 POLE, 63 AMP, 18-8 AWG
6-3
2
1082.00056.00
SCREW, # 8-16 x 1" PAN HD PHIL, THREAD FORMING, FOR PLASTICS, 18-8 SS
6-4
2
1058.00024.00
SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC
6-5
4
1057.00043.00
SOLENOID VALVE, 5.5L/min, 180 DEG, 24VDC
6-6
2
1082.00010.00
SCREW, PAN HD. PHIL. MACH., M4x10 ZINC-PLATED
6-7
1
1052.00059.00
POWER SUPPLY, 90-264VAC/24VDC, 2.25A
6-8
2
1082.00020.00
SCREW, #6 X 5/8, TRUSS HD PHIL, SHEET MTL
6-9
2
1058.00055.00
USB CONNECTOR
7
1
1097.00171.00
ADHESIVE, RGB LED BAR
8
1
1023.00390.00
LENS, LIGHT BAR, BLACK
9
2
1102.00450.00
QUICK CONNECT SRAYHEAD ASSEMBLY, BASIC [See Page 24 for expanded drawing]
10
4
1024.00107.00
O-RING, 1 3/16" OD X 1 1/16" ID X 1/16" TH, BYPASS SEAL
11
2
1024.00108.00
O-RING, 5 11/16"OD X 5 1/2" ID X 3/32" TH, BREW SEAL
12
3
1024.00106.00
O-RING, 13/16"OD X 11/16"ID X 1/16" TH, FOR QUICK CONNECT
13
2
1023.00343.00
VENT INSERT, QUICK CONNECT
14
4
1023.00342.00
QUICK CONNECT CLIP
15
20
1083.00010.00
WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
16
20
1084.00006.00
NUT, 8-32 18-8 HEX MACHINE SCREW
17
2
1024.00098.00
VENT TUBE, CBS- EXTRACTOR SERIES
18
2
1086.00004.00
BUSHING, SNAP, 1" MOUNTING HOLE
19
1
1102.00243.00
ADAPTER ASSY, 3/4" BSP x 1/4" NPT x 3/8" TUBE
20
2
1065.00009.00
GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
21
1
1044.00012.00
LABEL GROUND, CE
22
12
1084.00011.00
NUT, CLIP ON (J-NUT), #6-32, 22-20 GA., BLK-PH FINISH
23
1
1025.00058.00
TUBE, 9/16"OD X 5/16"ID X 25.00"LG
24
1
1086.00009.00
CLAMP, 3/4" MAX TUBE OD FLOW CONTROL
25
4
1086.00003.00
UNICLAMP, 15.9 HOSE OD CLAMP
26
1
1112.00529.00
WELDMENT FRONT COVER, CBS-2250 1½ gallon brewer and 2 gallon brewer
27
1
1001.00352.00
COVER, UPPER BASE, CBS-1152 EXTRACTOR V+
28
1
1001.00399.00
COVER TOP, CBS-2252
29
12
1082.00017.00
SCREW, TRUSS HD. PHIL. MACHINE, # 6-32 X 1/2 LG.
30
1
1046.00035.00
LABEL, WARNING "TO REDUCE RISK OF ELECTRIC SHOCK OR FIRE"
31
1
1402.00097.10
WIRE HARNESS, CBS-1240/50, LOW AMP, UNIVERSAL
32
1
1402.00097.11
WIRE HARNESS ADDITION, CBS-1252, LOW AMP, UNIVERSAL
33
2
1046.00003.00
LABEL, CSD WARNING, 1.5" X 5.0"
34
1
1041.00033.00
BLACK EXTRACTOR PLUS LABEL, LASER ENGRAVED
35
1
1104.00160.00
TANK ASSEMBLY, CBS-2252, 3 X 3KW/240VAC [See additional pages for expanded drawing]
35
1
1104.00161.00
TANK ASSEMBLY, CBS-2252, 2 X 3KW/240VAC [See additional pages for expanded drawing]
35
1
1104.00162.00
TANK ASSEMBLY, CBS-2252, 3 X 4KW/240VAC [See additional pages for expanded drawing]
35
1
1104.00163.00
TANK ASSEMBLY, CBS-2252, 3 X 5KW/240VAC [See additional pages for expanded drawing]
35
1
1104.00164.00
TANK ASSEMBLY, CBS-2252, 2 X 5KW/240VAC [See additional pages for expanded drawing]
36
1
1402.00112.10
WIRE HARNESS, CBS-1252/61, HIGH AMP, 1 OR 3PH, 3 HEATERS, UL
37
1
1402.00120.10
WIRE HARNESS, 3 HEATER, HIGH AMP, 3L-N-PE, 220/380-240/415, INTL/CE
38
1
1022.00032.00
SLEEVE, Ø.50 x 2.0" LG. x 1.50" SLOT
39
1
1066.00003.00
CABLE TIE, 3-7/8" LG., BLACK
40
1
B015280BN2BK
BREW BASKET ASSY BLACK, 16" X 6", 0.280" DIA HOLE, BROWN PLUG
41
1
B001280B1BB
ASSY, 16" X 6", 0.280 DIA HOLE, BLACK
42
1
B002280B1BB
ASSY, 16" X 6", 0.280" DIA HOLE, BLACK
43
1
1024.00111.00
GROMMET, SILICONE, W/ POSITION TABS
44
1
1023.00362.00
FITTING VENT, ELBOW, .375" X .375", SELF POSITIONING
45
1
1013.00131.00
TUBE, 304SS, .625OD X .065 WALL X 11-1/2" LG.
46
1
1023.00348.00
HOT WATER INSERT, MANUAL FAUCET
47
1
1071.00055.00
FAUCET, HOT WATER, PSC-BR-8, WITH FLAT AND STEM
48
1
1084.00048.00
JAM NUT, 1/2-20 UNF, NICKEL PLATED BRASS
49
1
1003.00370.00
HOT WATER INSERT LOCK
50
1
1025.00120.00
TUBE, 9/16"OD X 5/16"ID X 13.00"LG
51
1
1024.00051.00
GROMMET, SILICONE, BLANK
52
1
1023.00349.00
HOT WATER INSERT, NO FAUCET
53
1
1023.00369.00
ORIFICE INSERT, QUICK CONNECT, 3/16" HOLE
54
1
1057.00076.00
VALVE ASSEMBLY, COMPLETE, NG, DELTROL
55
1
1023.00344.00
PLUG INSERT, QUICK CONNECT
56
1
1029.00042.00
BYPASS L-TUBE, SILICONE, 2200 SINGLE SERIES
57
1
1102.00219.00
ASSEMBLY, BB LOCKER, 24VDC
58
1
1003.00259.00
BRACKET, BREW BASKET LOCK COVER
59
2
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
60
1
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
61
3
1073.00007.00
LEG, FLANGE FOOT, 4" HIGH
62
1
1086.00008.00
CONNECTOR, CLAMP, NON-METALLIC CABLE, 3/4"
63
1
1086.00031.00
SKINTOP, 3/4" NPT, 0.354" - 0.630" DIA CABLE, BLK
64
1
1086.00032.00
LOCKNUT, SKINTOP, 3/4" NPT, BLACK HEX
65
1
1044.00013.00
LABEL EQUIPOTENTIALITY, CE
66
1
1052.00050.00
EMI FILTER, 25A, 250/440VAC, 50/60Hz
67
1
1084.00012.00
NUT, HEX, #6-32 MACHINE SCREW
