FIBARO RGBW CONTROLLER 2 User Manual

13
operatIng tHe DevIce
7: Operating the device
7.1: Controlling the device using connected
switches
Controlling connected loads
Input can control output only with the same number (e.g. switch con-
nected to IN1 controls load connected to output OUT1). Perform fol-
lowing actions on inputs to change state of the connected load:
• 1xclick – change to the opposite one (ON/OFF)
• 2xclick – set to 100%
• hold/release – dimm/brighten
Other actions
• 3xclick – start learn mode to add/remove to/from Z-Wave network
• 1,2,3,4,5xclick/hold/release – activate scene in the controller for
specic action (requires prior conguration)
7.2: Visual indications
The built-in LED light shows current device status.
After powering the device:
• Green – device added to a Z-Wave network (without Security S2
Authenticated)
• Magenta – device added to a Z-Wave network (with Security S2
Authenticated)
• Red – device not added to a Z-Wave network
Update:
• Blinking cyan – update in progress
• Green – update successful (added without Security S2
Authenticated)
• Magenta – update successful (added with Security S2
Authenticated)
• Red – update not successful
Menu:
• 3 green blinks – entering the menu (added without Security S2
Authenticated)
• 3 magenta blinks – entering the menu (added with Security S2
Authenticated)
