FIBARO RGBW CONTROLLER 2 User Manual

17
confIguratIon
10: Conguration
10.1: Associations
Association (linking devices) - direct control of other devices within
the Z-Wave system network e.g. Dimmer, Relay Switch, Roller Shutter
or scene (may be controlled only through a Z-Wave controller).
Association ensures direct transfer of control commands between
devices, is performed without participation of the main controller
and requires associated device to be in the direct range.
The device provides the association of 10 groups:
1st association group – “Lifeline” reports the device status and al-
lows for assigning single device only (main controller by default).
2nd association group – “RGBW Sync” allows to synchronize state
of other FIBARO RGBW Controller 2 devices (do not use with other
devices).
3rd association group – “On/O (IN1)” is assigned to IN1 input ter-
minal (uses Basic command class).
4th association group – “Dimmer (IN1)” is assigned to IN1 input
terminal (uses Switch Multilevel command class).
5th association group – “On/O (IN2)” is assigned to IN2 input ter-
minal (uses Basic command class).
6th association group – “Dimmer (IN2)” is assigned to IN2 input
terminal (uses Switch Multilevel command class).
7th association group – “On/O (IN3)” is assigned to IN3 input ter-
minal (uses Basic command class).
8th association group – “Dimmer (IN3)” is assigned to IN3 input
terminal (uses Switch Multilevel command class).
9th association group – “On/O (IN4)” is assigned to IN4 input ter-
minal (uses Basic command class).
10th association group – “Dimmer (IN4)” is assigned to IN4 input
terminal (uses Switch Multilevel command class).
The device in 2nd to 10th group allows to control 5 regular or mul-
tichannel devices per an association group, with the exception of
“LifeLine” that is reserved solely for the controller and hence only 1
node can be assigned.
