16
actIvatIng scenes
9: Activating scenes
The device can activate scenes in the Z-Wave controller by sending
scene ID and attribute of a specic action using Central Scene Com-
mand Class.
In order for this functionality to work, connect monostable or bista-
ble switch to the IN1-IN4 inputs and set parameters 20-23 to 3, 4 or 5
(depending on type of switch).
By default scenes are not activated, set parameters 40-43 to enable
scene activation for selected inputs and actions.
Scene IDs for inputs
Input Scene ID
IN1 1
IN2 2
IN3 3
IN4 4
Attributes for actions
Action Attribute
Switch clicked once Key Pressed 1 time
Switch clicked twice Key Pressed 2 times
Switch clicked thrice* Key Pressed 3 times
Switch held** Key Held Down
Switch released** Key Released
* Activating triple clicks will disallow removing using input terminal.
** Not available for toggle switches.
