ZWAVE RANGE TEST
#12: Z-Wave range test
The device has a built in Z-Wave network main controller’s
range tester.
Follow the below instructions to test the main controller’s range:
1. Switch o the mains voltage (disable the fuse).
2. Remove the device from the wall switch box.
3. Switch on the mains voltage.
4. Press and hold the B-button to enter the menu.
5. Wait for the visual LED indicator to glow violet.
6. Quickly release and click the B-button again.
7. Visual indicator will indicate the Z-Wave network’s range (range
signalling modes described below).
8. To exit Z-Wave range test, click the B-button.
Z-Wave range tester signalling modes:
Visual indicator pulsing green - the device attempts to establish a
direct communication with the main controller. If a direct commu-
nication attempt fails, the device will try to establish a routed com-
munication, through other modules, which will be signalled by visual
indicator pulsing yellow.
Visual indicator glowing green - the device communicates with the
main controller directly.
Visual indicator pulsing yellow - the device tries to establish a rout-
ed communication with the main controller through other modules
(repeaters).
Visual indicator glowing yellow - the device communicates with
the main controller through the other modules. After 2 seconds the
device will retry to establish a direct communication with the main
controller, which will be signalled with visual indicator pulsing green.
Visual indicator pulsing violet - the device does communicate at the
maximum distance of the Z-Wave network. If connection proves suc-
cessful it will be conrmed with a yellow glow. It’s not recommended
to use the device at the range limit.
Visual indicator glowing red - the device is not able to connect to
the main controller directly or through another Z-Wave network de-
vice (repeater).
CAUTION
To make Z-Wave range
test possible, the de-
vice must be added
to the Z-Wave control-
ler. Testing may stress
the network, so it is
recommended to per-
form the test only in
special cases.
!
NOTE
Communication mode
of the device may
switch between direct
and one using rout-
ing, especially if the
device is on the limit
of the direct range.
i

FIBARO ROLLER SHUTTER 3 Specifications

General

Device Type	Roller Shutter Controller
Protocol	Z-Wave
Radio Protocol	Z-Wave
Dimensions	42.5 x 38.25 x 20.3 mm
Mounting Box Requirements	Ø ≥ 50mm, depth ≥ 60mm
Protection Class	IP20
Maximum Load for AC Output	4.2A
Max Transmit Power	up to 6 dBm
Range	Up to 50m (open space)
Operating Temperature	0°C to 40°C
Z-Wave Frequency	868.4 MHz EU
Compatibility	Works with various Z-Wave and Z-Wave Plus certified devices
Radio Frequency	868.4 or 908.4 or 921.4 MHz EU frequency band
