FIBARO ROLLER SHUTTER 3 User Manual

13
OPERATING ROLLER BLINDS
#6: Operating roller blinds
NOTE
Momentary switch
After releasing the
switch a spring auto-
matically pushes back
and disconnects the
switch)
Toggle switch
Operates as a two-po-
sition switch, it has no
spring that would set
one position of the
switch.
i
The device allows for connecting switch to the S1 and S2 terminals.
These may be momentary (recommended) or toggle switches.
Switch buttons are responsible for managing the blind’s movement.
Description:
– switch connected to the S1 terminal
– switch connected to the S2 terminal
Click switch – initiate up movement.
Click switch – initiate down movement.
If the blind is moving, clicking any button, will stop the move-
ment.
Operating slats of venetian blinds
When operating venetian blinds it is possible to manage angle
of the slats.
Hold switch – initiate slats rotation up.
Hold switch – initiate slats rotation down.
Using toggle switches:
Change switch state – initiate up movement.
Change switch state – initiate down movement.
Choosing a middle position stops the blinds.
Using momentary switches:

FIBARO ROLLER SHUTTER 3 Specifications

General

Device Type	Roller Shutter Controller
Protocol	Z-Wave
Radio Protocol	Z-Wave
Dimensions	42.5 x 38.25 x 20.3 mm
Mounting Box Requirements	Ø ≥ 50mm, depth ≥ 60mm
Protection Class	IP20
Maximum Load for AC Output	4.2A
Max Transmit Power	up to 6 dBm
Range	Up to 50m (open space)
Operating Temperature	0°C to 40°C
Z-Wave Frequency	868.4 MHz EU
Compatibility	Works with various Z-Wave and Z-Wave Plus certified devices
Radio Frequency	868.4 or 908.4 or 921.4 MHz EU frequency band
