FIBARO ROLLER SHUTTER 3 User Manual

21
ZWAVE SPECIFICATION
Command Class Version Secure
ZWAVEPLUS_INFO [0x5E] V2
SWITCH_MULTILEVEL [0x26] V4 YES
ASSOCIATION [0x85] V2 YES
MULTI_CHANNEL_ASSOCIATION [0x8E] V3 YES
ASSOCIATION_GRP_INFO [0x59] V2 YES
TRANSPORT_SERVICE [0x55] V2
VERSION [0x86] V2 YES
MANUFACTURER_SPECIFIC [0x72] V2 YES
DEVICE_RESET_LOCALLY [0x5A] V1 YES
POWERLEVEL [0x73] V1 YES
SECURITY [0x98] V1
SECURITY_2 [0x9F] V1
SUPERVISION [0x6C] V1
METER [0x32] V3 YES
CONFIGURATION [0x70] V1 YES
CRC_16_ENCAP [0x56] V1
NOTIFICATION [0x71] V8 YES
PROTECTION [0x75] V2 YES
MULTI_CHANNEL [0x60] V4 YES
CENTRAL_SCENE [0x5B] V3 YES
FIRMWARE_UPDATE_MD [0x7A] V4 YES
APPLICATION_STATUS [0x22] V1
BASIC [0x20] V1 YES
#14: Z-Wave specication
Endpoint 1:
Generic Device Class: GENERIC_TYPE_SWITCH_MULTILEVEL
Specic Device Class: SPECIFIC_TYPE_CLASS_B_MOTOR_CONTROL
Description: represents switch connected to the S1 terminal.
Endpoint 2:
Generic Device Class: GENERIC_TYPE_SWITCH_MULTILEVEL
Specic Device Class: SPECIFIC_TYPE_CLASS_B_MOTOR_CONTROL
Description: represents switch connected to the S2 terminal.
Supported Command Classes:
Switch Multilevel Command Class values refers to:
• 0x00 - fully close
• 0x63 - fully open

FIBARO ROLLER SHUTTER 3 Specifications

General

Device Type	Roller Shutter Controller
Protocol	Z-Wave
Radio Protocol	Z-Wave
Dimensions	42.5 x 38.25 x 20.3 mm
Mounting Box Requirements	Ø ≥ 50mm, depth ≥ 60mm
Protection Class	IP20
Maximum Load for AC Output	4.2A
Max Transmit Power	up to 6 dBm
Range	Up to 50m (open space)
Operating Temperature	0°C to 40°C
Z-Wave Frequency	868.4 MHz EU
Compatibility	Works with various Z-Wave and Z-Wave Plus certified devices
Radio Frequency	868.4 or 908.4 or 921.4 MHz EU frequency band
