FIBARO ROLLER SHUTTER 3 User Manual

12
POSITIONING CALIBRATION
Roller blind with built-in driver positioning
1. Make sure:
• the device is supplied,
• momentary switch is connected to S1 and S2 terminals,
• the device added to the Z-Wave network,
• parameter 151 is set to 5 or 6.
2. By default, time of transition between extreme positions is
set to 600 (6 seconds) in parameters 155 and 156.
3. Move roller blinds between extreme positions by clicking
or switch:
• If roller blind stops before reaching top - increase value
of parameter 155,
• If roller blind does not stop after reaching top - decrease
value of parameter 155,
• If roller blind stops before reaching bottom - increase val-
ue of parameter 156,
• If roller blind does not stop after reaching bottom - de-
crease value of parameter 156,
4. Repeat previous step until satisfactory positioning is
achieved.
5. Test whether the positioning works correctly.

FIBARO ROLLER SHUTTER 3 Specifications

General

Device Type	Roller Shutter Controller
Protocol	Z-Wave
Radio Protocol	Z-Wave
Dimensions	42.5 x 38.25 x 20.3 mm
Mounting Box Requirements	Ø ≥ 50mm, depth ≥ 60mm
Protection Class	IP20
Maximum Load for AC Output	4.2A
Max Transmit Power	up to 6 dBm
Range	Up to 50m (open space)
Operating Temperature	0°C to 40°C
Z-Wave Frequency	868.4 MHz EU
Compatibility	Works with various Z-Wave and Z-Wave Plus certified devices
Radio Frequency	868.4 or 908.4 or 921.4 MHz EU frequency band
