FIBARO ROLLER SHUTTER 3 User Manual

11
POSITIONING CALIBRATION
Calibration using parameter
1. Make sure:
• the device is supplied,
• the device added to the Z-Wave network,
• parameter 151 is set to 1 or 2.
2. Set the parameter 150 value to 2
3. The device will perform the calibration process, completing
full cycle – up, down and up again
4. The parameter 150 value will be set to 1 after calibration n-
ishes.
5. Test whether the positioning works correctly.
Slats positioning in venetian blinds mode
Calibration using connected momentary switch
1. Make sure:
• the device is supplied,
• momentary switch is connected to S1 and S2 terminals,
• the device added to the Z-Wave network,
• parameter 151 is set to 2,
• blinds are calibrated.
2. By default, time of transition between extreme positions is
set to 150 (1.5 seconds) in parameter 152.
3. Turn slats between extreme positions by holding or
switch:
• If after full cycle a blind starts moving up or down - de-
crease value of parameter 152,
• If after full cycle the slats does not reach end positions -
increase value of parameter 152,
4. Repeat previous step until satisfactory positioning is
achieved.
5. Test whether the positioning works correctly. Correctly con-
gured slats should not force the blinds to move up or down.

FIBARO ROLLER SHUTTER 3 Specifications

General

Device Type	Roller Shutter Controller
Protocol	Z-Wave
Radio Protocol	Z-Wave
Dimensions	42.5 x 38.25 x 20.3 mm
Mounting Box Requirements	Ø ≥ 50mm, depth ≥ 60mm
Protection Class	IP20
Maximum Load for AC Output	4.2A
Max Transmit Power	up to 6 dBm
Range	Up to 50m (open space)
Operating Temperature	0°C to 40°C
Z-Wave Frequency	868.4 MHz EU
Compatibility	Works with various Z-Wave and Z-Wave Plus certified devices
Radio Frequency	868.4 or 908.4 or 921.4 MHz EU frequency band
