IG‐541(52%Nitrogen,40%Argon,and8%CarbonDioxideMixture)
TheIG‐541inertgasmixtureconsistsnominallyof52%nitrogen,40%argon,and8%carbondioxide.Themixture
specificationisnitrogen52±4%,argon40±4%,carbondioxide8+1%/‐0%.Detailedbelowarethestepsnecessary
to
fillthePROINERTcontainerwithIG‐541.
Connecttothevalveoutletandpull25"to27"ofvacuumtoremoveresidualatmosphereandmoisture.
Fillthecontainerviathevalveinletwiththeindividualgasesinthefollowingorder:Carbondioxide,then
argon,andthennitrogen,asdetailedinthetablebelowforthesystempressurerequired:
Size
(Liters)
Carbon
Dioxide
(kg)
Argon
(kg)
Nitrogen
(kg)
Resultant
IG‐541
(kg)
FinalFill
Pressure
@15°C(bar)
FinalFillPressure
@59°F(psi)
80 2.47–2.49 10.76–11.66 9.81 –10.63 23.04–24.78 200 2,900
80 3.50–3.54 14.82–16.06 13.49–14.61 31.81–34.21 300 4,350

NOTE: Performapreliminaryleakcheckatthecylinderneckwithasoapsolution(SwageLokSnooporequivalent)
onceithasbeenfilledhalfwaywithargon.Ifaleakisdetected,discontinuethefillforthatparticular
cylinder.
Verifythecontainerbyensuringthatthefinalfillpressureisasdetailedaboveat59°F(15°C).Ifrequired,
refertothepressurevs.temperaturechartforIG‐541inAppendixA.2.
Closevalvebyunscrewingthecentralscrewonthefillingadaptorandremovethetophalfoftheadaptor.
Noticethedowelontheinternalpieceofthefillingadaptormovedownwardsduringthisoperation.
ProceedwithremovalofthebottomhalfofthefillingadaptorbyunscrewingthetwoM6setscrews.Remove
thisadaptorfromvalveandcheckthatthespringwasherhasdroppedlowerthanitsoriginaldepth.
Ventthefillinghoseandcheckthatthereisnoflowfromthevalveoutlet.
Fitthevalvelockoutassembly ontothevalve(Figure4.2.3‐1)priortoremovingthefillinghose.
Removethefillinghoseandscrewtherecoilcapontothedischargeoutlet.
Removethevalvelockoutassemblyfromthevalveaftertherecoilcaphasbeenfitted.
Proceedtoleakchecking(Section5).
Checkthecontainerpressure(Section6).
Oncetestingiscomplete,screwthesh ipping/safetycapontothecylinder.
Figure4.2.3‐1IG‐541ContainerwithValveLockoutAssemblyInstalled
ValveLockout
