8.0 CYLINDERPACKAGING
Cylindersmustnotbeshippedwithanystraymarks,missingpaint,orscratches.Anymarksmustbewipedoffwitha
non‐solventbasedcleaner.Anymissingpaint,scratches,ormarksthatcannotberemovedwillbetouchedupusing
touchuppaintofthesamecolor(RAL3001)andsheen.Theserequirementsdonotapplytothebottomofthe
cylinder.
Cylinderdentsanddingswillbeevaluatedandsortedper
ENISO9809‐2,AnnexA.
8.1 PackagingMaterials
Cylinderswillbeshippedusingthefollowingmaterials:
 Woodpallet,heat‐treatedperISPM15
 Corrugatedcardboardandnylonsleeves
 2x4 lumber,heat‐treatedperISPM15
 8‐penny(8D)ringshanknails
 3"drywallorwoodscrews
 1.25"‐widesteelbanding
 2"‐wide
ratchetstrap
 DOTClass2label
 UN label
 OVERPACKlabel
 SDSwithplasticpouch
8.2 PackagingProcedure
PriortopalletizingPROINERTcontainerassemblies,validatethestrengthandqualityoftheskidandwooden
frame.Allboardswillbejoinedusingaminimumofthreeequallyspacednailsperjoint.
PalletizethePROINERTcontainerassembliespertheconfigurationsbeloworaFike‐approvedconfiguration
(notshown).
NOTE: Oneortwocylinderordersmaybepackaged
individuallywithoutapallet;however,3+
cylinderorderscannot.
One(1)DOTlabel,one(1)UNlabel,andone
(1)OVERPACKlabelmustbeappliedtothe
corrugatedcardboardsleeveofonecontainer
perpallet,asshowninFigure8.2‐1.Labels
mustbeprominentlydisplayedwhenfinished.
Placeacopy ofthePROINERTagentSDSina
plasticpouchandsecurethepouchtothe
outsideofthecorrugatedcardboard.TheSDS
mustbeprominentlydisplayedwhenfinished.
Continuetothehorizontalandvertical
packagingconfigurationsforwoodandsteel
pallets.


AGENT UNLABEL
IG‐55
UN1956
COMPRESSEDGAS
N.O.S.
IG‐55(NITROGEN,
ARGON)
IG‐100
UN1066
NITROGEN,
COMPRESSED
IG‐100(NITROGEN)
IG‐541
UN1956
COMPRESSEDGAS
N.O.S.
IG‐541(NITROGEN,
ARGON,
CARBONDIOXIDE)
Figure8.2‐1
PackagingLabel
Specifications
