Doc.P/N06‐312

Rev.11/March2020

PAGE/13



7.0 CYLINDERIDENTIFICATIONLABEL

Thefillstationwillupdatethecylinderidentificationlabelwiththeinformationshownbelowusingamedium‐orfine‐

pointpermanentblackmarker.



Figure7.0‐1SampleCylinderIden tificationLabel



7.1 LabelPlacement

Step1. Cleanthesurfaceandapplythelabelapproximately45left

oftheCEmarkonthevalveassembly.

Step2. Applythesafetycaplabeltothesafetycap.

NOTE:ThecylinderIDlabelshouldbeattached47”(1194mm)from

thebottomofthecylinder.

Step3. PositiontheoverlaymentoverthecylinderIDlabelsoit

coverstheoriginalfilldateandthefilldateandULfill

stationcodenumber.

Step4. Applythefillpressureandhazardclasslabelsbelowthe

cylinderIDlabelasshown.



 







    

 

SafetyCap

Label

CylinderIDLabel

Overlayment

FillPressure

HazardClass

47"

(1194mm)

Figure7.1‐2

LabelPlacementDetails



Figure7.1‐1LabelPlacement


