Fimap MAXIMA 2017 PLUS - TECHNICAL DATA

TECHNICAL DATA
Remarks:
(1) Machine weight: refers to the overall machine weight without the batteries, and with both tanks empty.
(2) Machine weight during transport: refers to the overall machine weight with the batteries, but with both tanks empty.
(3) Machine weight during work operations: refers to the overall machine weight with the batteries, with the solution tank full and the detergent canister full (valid for FSS versions), but with the recovery tank
empty.
11
TECHNICAL DATA
Unit of measurement
symbol
MAXIMA 2017
PLUS 50BT
MAXIMA 2017
PLUS 60BT
MAXIMA 2017
PLUS 50BTO
MAXIMA 2017
PLUS 50BTS
Rated machine power W 1075 1575 1255 1275
Working capacity up to sq.m. 1785 2118 1778 1771
Working width mm 510 605 508 506
Squeegee width mm 712 782 712 800
Brush head brush diameter (number - diameter) mm 1 - 510 2 - 300 - -
Dimensions of abrasive pad (width x depth) mm - - 508 x 355 -
Dimensions of cylindrical brush (diameter - length) mm - - - 150 - 506
Number of brush head brush rotations rpm 140 - 600
Number of pad oscillations rpm - - 2400 -
Brush head motor (voltage / nominal power) V / W 24 - 500 24 - 500 24 - 680 24-350
Maximum weight exerted on the brush head kg 36
Maximum possible gradient for uphill and downhill movement
(weight
(2)
)
% 10
Maximum slope during ascent and descent with the transport
program (weight
(2)
)
% 10
Maximum ambient temperature for machine operation °C +40
Minimum ambient temperature for using the machine's scrubbing
functions
°C 0
Traction motor (voltage / rated power) V / W 24 - 150
Maximum forward speed in transport mode Km/h 3.5
Vacuum motor (voltage - nominal power rating) V / W 24 - 422
Vacuum on vacuum head mbar 120,62
Maximum solution tank capacity l 60
Maximum recovery tank capacity l 65
Machine dimensions (length - width - height) mm 1295 - 712 - 1095 1220 - 712 - 1095 1265 - 785 - 1095
Battery compartment dimensions (width - useful height - length) mm 485 - 253 - 351
Recommended battery V / AhC
5
12 - 112
Maximum individual battery weight (recommended) kg 39
Machine weight
(1)
kg 112
Machine weight during transport
(2)
kg 190
Machine weight during work operations
(3)
kg 245
Sound pressure level (ISO 11201) - L
pA
dB (A) <70 <70 <70 <70
Uncertainty K
pA
dB (A) 1,5 1,5 1,5 1,5
Hand vibration level (ISO 5349) m/s
2
<2,5 <2,5 <2,5 <2,5
Vibration measurement uncertainty - - - -
