EN
15
Bracket Model Description
PVS-100/120-TL-BRACKET Bracket allowing both vertical and horizontal installation.
Wiring Box Model Description
WB-PVS-100-TL
WB-PVS-120-TL
• 1 or 2 MPPTs (settable on the field)
• 4 DC cable glands (2xM40 cable glands for each MPPTs)
• 4 DC connection bus bars (1 pair for each MPPT)
• Input current monitoring (MPPT level)
• DC SPD type II (monitored)
• AC plate with 5 individual AC cable glands: 4 x M40 and 1 x M25
• 4 AC connection bus bars (3 Phases + Neutral)
• AC SPD type II (replaceble)
WB-S2-PVS-100-TL
WB-S2-PVS-120-TL
• 1 or 2 MPPTs (settable on the field)
• 4 DC cable glands (2xM40 cable glands for each MPPTs)
• 4 DC connection bus bars (1 pair for each MPPT)
• Input current monitoring (MPPT level)
• DC SPD type II (monitored)
• DC disconnect switch
• AC plate with 5 individual AC cable glands: 4 x M40 and 1 x M25
• 4 AC connection bus bars (3 Phases + Neutral)
• AC SPD type II (replaceble)
• AC disconnect switch
WB-SX-PVS-100-TL
WB-SX-PVS-120-TL
• 6 MPPTs
• Input with 24 quick fit connectors pairs (4 each MPPT)
• Input current monitoring (MPPT level)
• String fuses (positive pole)
• DC SPD type II (monitored)
• DC disconnect switch
• AC plate with 5 individual AC cable glands: 4 x M40 and 1 x M25
• 4 AC connection bus bars (3 Phases + Neutral)
• AC SPD type II (replaceble)
WB-SY-PVS-100-TL
WB-SY-PVS-120-TL
• 6 MPPTs
• Input with 24 quick fit connectors pairs (4 each MPPT)
• Input current monitoring (MPPT level)
• String fuses (positive pole)
• DC SPD type I + II (monitored)
• DC disconnect switch
• AC plate with 5 individual AC cable glands: 4 x M40 and 1 x M25
• 4 AC connection bus bars (3 Phases + Neutral)
• AC SPD type II (replaceble)
WB-SX2-PVS-100-TL
WB-SX2-PVS-120-TL
• 6 MPPTs
• Input with 24 quick fit connectors pairs (4 each MPPT)
• Input current monitoring (string level)
• String fuses (positive and negative pole)
• DC SPD type II (monitored)
• DC disconnect switch
• AC plate with 5 individual AC cable glands: 4 x M40 and 1 x M25
• 4 AC connection bus bars (3 Phases + Neutral)
• AC SPD type II (replaceble)
• AC disconnect switch
WB-SY2-PVS-100-TL
WB-SY2-PVS-120-TL
• 6 MPPTs
• Input with 24 quick fit connectors pairs (4 each MPPT)
• Input current monitoring (string level)
• String fuses (positive and negative pole)
• DC SPD type I + II (monitored)
• DC disconnect switch
• AC plate with 5 individual AC cable glands: 4 x M40 and 1 x M25
• 4 AC connection bus bars (3 Phases + Neutral)
• AC SPD type II (replaceble)
• AC disconnect switch
NOTE – D All inverter models can be equipped with PVS-100/120 GROUNDING KIT and/or PVS-100/120 PRE-CHARGE BOARD
KIT. Kits can be installed in the field by qualified installers and/or licensed electricians, with experience in photovoltaic systems. Kits
may also be pre-installed in the factory on dedicated P/N’s. Refer to instruction provided together with kits for a proper installation
and/or configuration.
