Fincor 2602 - Allowable Option Combinations

BOOK0795-F
30
TABLE 7. ALLOWABLE OPTION COMBINATIONS
OPTION TYPE
OPTION
GROUP
OPTION
NUMBER
OPTION
CODE
a
a. XK = Factory Installed Or Field Kit
K = Field Kit
P = Plug-In Option
OPTION
Enclosure Options - Choice of any or all
within this group. May be combined with
options from any other groups.
A 1638 XK Hinge, Enclosure Cover (Models 2601 And 2602 Only)
A 1170A XK
Fan Assembly (5 HP Units Only) (Required When Enclosed
Model 2602 Is Operated At 5 HP Rating)
Options Used To Convert Open Chassis
Units Into Enclosed Package Control-
lers - Choice of one within this group. May
be combined with options from any other
groups.
B 1639 XK Cover Assembly, Blank Type P0
B 1639C XK Cover Assembly, Type P1
B 1639E XK Cover Assembly, Type P2
B 1639G XK Cover Assembly, Type P3
Power Options
C 1010 XK Circuit Breaker - Two Pole (Model 2601 Only)
C 1014 XK AC Line Switch (Model 2602 Only)
C 1004 XK
Armature Contactor Reversing With Dynamic Braking (May Be
Combined With All Options In This Group)
Input Signal Options - Choice of one
within this group unless Option 1037 is
selected. May be combined with options
from any other groups except Group F.
Option 1775 is required for all options in
this group.
D 1775 XK Interface, Signal Options
D 1037 XK, P Input, External Interface
D 1049 XK, P Follower, External DC Signal
D 1050 XK, P Follower, External AC Signal
D 1050A XK, P Follower, AC Current Transducer
D 1051 XK, P Follower, MIRC
D 1055 XK, P Follower, AC Or DC Tachometer Generator
D 1057A XK, P Follower, Digital Pulse Generator
D 1059 XK, P Precision Reference
Feedback Options - Choice of one within
this group unless Option 1037 is selected.
May be combined with options from any
other groups except Group F. Option 1775
is required for all options in this group.
E 1775 XK Interface, Signal Options
E 1037 XK, P Feedback, External Interface
E 1061C XK, P Feedback, AC Or DC Tachometer Generator
E 1061F XK, P Feedback, AC Or DC Tachometer Generator With Tach Loss
E 1062A XK, P Feedback, Digital Pulse Generator
E 1064 XK, P Torque (Current) Limit Control
E 1190 XK, P Torque Taper
Input And Feedback Options - May be
combined with options from any other
groups except Groups D and E.
F 1064A XK Follower, Current Regulator
F 1191 XK Centerwind Torque Control
F 1220 XK Constant Velocity Winder
External Options - Choice of any or all
within this group
G 1120 K Operator Control Station - Remote
G 1120A K Motor Speed Potentiometer, Ten-Turn With Analog Dial
G 1120B K Motor Speed Potentiometer, One-Turn
G 1120C K Motor Speed Potentiometer, Ten-Turn With Digital Dial
G 1022 K Jog, Toggle Switch Selection
G 1058A K Follower/Manual Mode Select Switch
G 1037A K Input-Feedback Adapter, External - One Position
G 1166 K Equipment Manual
Miscellaneous Options - Choice of any or
all within this group when mounted exter-
nally. Choice of one when mounted in a
Model 2601 or 2602. May be combined
with options from any other groups.
H 1047 XK Controlled (Ramp) Stop
H 1081B XK Current (Torque) Monitor
H 1015 XK Magnetic Control Interface (115V)
