BOOK0795-F
34
OPERATING CONDITIONS
1. Altitude, Standard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000 Meters (3300 Feet) Maximum.
1
2. Ambient Temperature
2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 - 40°C (32°F - 104°F)
3. Line Frequency Variation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 2 Hz Of Rated
4. Line Voltage Variation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±10% Of Rated
5. Relative Humidity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95% Noncondensing
TABLE 11. CONTROLLER WEIGHTS
CONTROLLER MODEL WEIGHT - LBS (KG)
Rated Horsepower (HP) 1/6 - 2 3 5
2601 7.70 (3.50) NA
2602 8.20 (3.72) 8.60 (3.90)
2601A 8.50 (3.86) NA
2602A 8.90 (4.04) 9.30 (4.22)
2601P0, P1, P3 11.60 (5.26) NA
2602P0, P1, P3 12.10 (5.49) 12.50 (5.67)
2601AP0, P1, P3 12.40 (5.62) NA
2602AP0, P1, P3 12.80 (5.81) 13.20 (6.00)
2611, 2612 3.25 (1.47) NA
2611A, 2612A 3.80 (1.72) NA
2611P0, P1, P2 5.50 (2.50) NA
2611AP0, P3 6.05 (2.74) NA
1. Controller can be derated by 1% per 100 meters to operate at higher altitudes.
2. 55°C (131°F) maximum in enclosed areas where open-chassis controllers are mounted.
TABLE 10. OPERATING VOLTAGES AND SIGNALS
POWER SOURCE
(Single-Phase)
OUTPUT VDC SPEED
REFERENCE
SIGNAL
a
a. Grounded or ungrounded. Choice of one.
MAGNETIC
CONTROL
VOLTAGE
Armature Field
115V, 50 or 60 Hz 0 - 90 50/100 0 - 5 VDC,
0 - 10 VDC,
4 - 20 mA
24 VDC
230V, 50 or 60 Hz 0 - 180 100/200
