RATINGS AND SPECIFICATIONS
RATINGS
1. Current/Torque Reference Potentiometer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5K Ohms, 1/2W
2. Duty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Continuous
3. Horsepower Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/6 - 5 HP (See Table 1, Page 1)
4. Line Fuse Interrupting Capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100,000 Amperes
5. Line Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115V Or 230V, Single-Phase, 50 Or 60 Hz
6. Motor Speed Potentiometer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5K Ohms, 1/2W
7. Overload Capacity, Armature Circuit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150% For 1 Minute
8. Service Factor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0
TABLE 9. TYPICAL APPLICATION DATA
COMPONENT RATINGS
RATED HORSEPOWER (HP) 1/6 1/4 1/3 1/2 3/4 1 1-1/2 2 3 5
RATED KILOWATTS (kW) 0.124 0.187 0.249 0.373 0.560 0.746 1.120 1.492 2.238 3.730
1-PHASE
AC INPUT
(FULL-LOAD)
Line
Amps
115V
Unit
3.9 5.0 6.0 8.7 12.4 15.8 NA NA NA NA
230V
Unit
NA NA NA 4.2 5.9 8.8 12.6 15.8 22.0 32.0
KVA 0.48 0.58 0.71 1.00 1.40 2.00 3.00 4.00 5.00 8.00
DC OUTPUT
(FULL-LOAD)
Motor
Armature
Amps
90V 2.0 2.8 3.5 5.4 8.1 10.5 NA NA NA NA
180V NA NA NA 2.6 3.8 5.5 8.2 11.6 15.1 25.0
Motor
Field
Amps
(Maximum)
Series
2600
2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Series
2611
1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 NA NA
Series
2612
1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 NA
FULL-LOAD TORQUE (lb-ft) with
1750 RPM Base Speed Motors
0.5 0.75 1.0 1.5 2.2 3.0 4.5 6.0 9.0 15.0
MINIMUM TRANSFORMER KVA FOR
VOLTAGE MATCHING OR ISOLATION
0.5 0.75 0.75 1.0 1.5 2.0 3.0 5.0 7.5 10.0
