TABLE 2. SERIES 2610 MODEL MATRIX
MOTOR SELECTION
Series 2600/2610 Controllers control the operation of general purpose DC motors designed for use with
solid-state rectified power supplies. The motor may be shunt-wound, stabilized shunt-wound, or permanent mag-
net. For maximum efficiency, the motor should be rated for operation from a NEMA Code K power supply.
MODEL
FUNCTION CONFIGURATION
OPERATOR
CONTROLS
POWER
SOURCE
a
&
HP RANGE
a. Units are reconnectable
RUN-
STOP
b
b. No armature contactor
RUN-
STOP-
DB
c
c. Includes armature contactor
ARMATURE
SWITCH
REVERSE
b
ARMATURE
CONTACTOR
REVERSE
AND DB
c
OPEN
CHASSIS
ENCLOSED
LOCAL
INTEGRAL
REMOTE 115V 230V
2611 X X X
1/6 - 1 1/3 - 2
2611P0 X X X
2611P1 X X X
2611P2 X X X
2611A X X X X
2611AP0 X X X X
2611AP1 X X X
2611AP3 X X X
2612 X X X
1/6 - 1 1/3 - 3
2612A X X X X
