Fincor 2602 - Series 2600;2610 Control Board, 1;6 - 3 HP

BOOK0795-F
43
CONNECTOR J5
ACCELERATION POT
DECELERATION POT
MAXIMUM SPEED POT
MINIMUM SPEED POT
CURRENT LIMIT POT
IR/TACH POT
CURRENT LIMIT
INDICATOR
DIP SWITCH S3
LOGIC & SIGNAL
CONNECTION
TERMINALS
AC LINE
CONNECTION
TERMINALS
MOTOR SHUNT FIELD
CONNECTION
TERMINALS
MOTOR ARMATURE
CONNECTION
TERMINALS
CONNECTOR E2
CONNECTOR E1
AC LINE FUSE F1
115V/230VAC
JUMPER J1
(Shown in
230VAC Position)
MOTOR CURRENT
JUMPER J4
90V/180VDC
JUMPER J2
(Shown in
180VDC Position)
90V/180VDC
JUMPER J3
(Shown in
180VDC Position)
FIGURE 22. SERIES 2600/2610 CONTROL BOARD, 1/6 - 3 HP
