PERFORMANCE CHARACTERISTICS
1. Controlled Speed Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 To Motor Base Speed
2. Displacement Power Factor (Rated Speed/Rated Load). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87%
3. Efficiency (Rated Speed/Rated Load)
a. Controller Only. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98%
b. Controller With Motor, Typical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85%
4. Speed Regulation. . . . . . . . . Regulation percentages are of motor base speed under steady-state conditions
TABLE 12. SPEED REGULATION CHARACTERISTICS
ADJUSTMENTS
1. Acceleration, Linear. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.2 - 30 Seconds
2. Deceleration, Linear. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.2 - 30 Seconds
3. IR (Load) Compensation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 - 10% Boost
4. Jog Speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 - 100% Of Motor Base Speed
5. Maximum Speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50% - 100% Of Motor Bas e Speed
6. Minimum Speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 - 40% Of Motor Base Speed
7. Torque (Current) Limit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 - 150% Of Full-Load Torque
REGULATION
METHOD
VARIABLE
Load
Change
(95%)
Line
Voltage
(±10%)
a
a. With Precision Reference (Option 1059), regulation due to ±10% line voltage
change is ± 0.1%.
Field
Heating
(Cold/Normal)
Temperature
(±10°C)
Speed
Range
Standard Voltage
Feedback with IR
Compensation
2% ±1% 5 - 12% ±2% 50:1
Optional Speed
(Tach) Feedback
(Option 1061C)
with Sigmation or
5PY DC Tach
b
b. Speed regulation characteristics are based on the use of Fincor Electronics cata-
loged motors and tachometer generators. Regulation characteristics cannot be guar-
anteed with motors and/or tachometer generators that have not been evaluated.
0.5% ±1% 0.2% ±2% 200:1
