Fincor 2602 - Series 2600 Control Board, 5 HP

BOOK0795-F
44
ACCELERATION POT
CONNECTOR J5
DECELERATION POT
MAXIMUM SPEED POT
CURRENT LIMIT POT
CURRENT LIMIT
INDICATOR
IR/TACH POT
MINIMUM SPEED POT
DIP SWITCH S3
LOGIC & SIGNAL
CONNECTION
TERMINALS
AC LINE FUSE F1
AC LINE
CONNECTION
TERMINALS
MOTOR SHUNT FIELD
CONNECTION
TERMINALS
MOTOR ARMATURE
CONNECTION
TERMINALS
115V/230VAC
JUMPER J1
(Shown in
230VAC Position)
MOTOR CURRENT
JUMPER J4
90V/180VDC
JUMPER J2
(Shown in
180VDC Position)
90V/180VDC
JUMPER J3
(Shown in
180VDC Position)
CONNECTOR J7
CONNECTOR J6
FIGURE 23. SERIES 2600 CONTROL BOARD, 5 HP
