Parameter setting- Output/Input signal setting
Data Type
Unit
Range
Definition
Authority
0x1090
4240
PFC_IO_SIGNAL_SET_DAMPING_TIME
UINT16
Second
000~+100(Default:3)
Output/Input signal
setting/ Input signal
average time
Read /Write
0x1091
4241
PFC_IO_SIGNAL_SET_PULSE_OUTPUT_MODE
UINT16
N/A
0:NO
1:NC
2: Frequency output
Pluse output mode
Read /Write
0x1092
4242
PFC_IO_SIGNAL_SET_PULSE_OUTPUT_UNIT-High
FLOAT64
Liter
+0.0010~+99.999
(Default:0.01)
Pluse unit setting
Read /Write
0x1093
4243
PFC_IO_SIGNAL_SET_PULSE_OUTPUT_UNIT+1
Read /Write
0x1094
4244
PFC_IO_SIGNAL_SET_PULSE_OUTPUT_UNIT+2
Read /Write
0x1095
4245
PFC_IO_SIGNAL_SET_PULSE_OUTPUT_UNIT-Low
Read /Write
0x1096
4246
PFC_IO_SIGNAL_SET_MAX_FREQ-High
FLOAT64
Hz
+0.0010~8.000
(Default:2.0)
Frequency setting
Read /Write
0x1097
4247
PFC_IO_SIGNAL_SET_MAX_FREQ+1
Read /Write
0x1098
4248
PFC_IO_SIGNAL_SET_MAX_FREQ+2
Read /Write
0x1099
4249
PFC_IO_SIGNAL_SET_MAX_FREQ-Low
Read /Write
0x109A
4250
PFC_IO_SIGNAL_SET_OUTPUT_CURR_MODE
UINT16
mA
0: 4-20mA
1: 0-20mA
Current output mode
Read /Write
0x109B
4251
PFC_IO_SIGNAL_SET_4MA_FINE_TUNE
INT16
Count
-5000.0~+5000.0
(Default:0)
4mA output
adjustment
Read /Write
0x109C
4252
PFC_IO_SIGNAL_SET_20MA_FINE_TUNE
INT16
Count
-5000.0~+5000.0
(Default:0)
20mA output
adjustment
Read /Write
0x109D
4253
PFC_IO_SIGNAL_SET_DIGITAL_1_IN_FUNC
UINT16
N/A
0: none
1: Reset
Input1 contact
function
Read /Write
0x109E
4254
PFC_IO_SIGNAL_SET_DIGITAL_1_IN_TYPE
UINT16
N/A
0:NO
1:NC
Input1 contact form
Read /Write
