FineTek EPD30 - Page 38

35
0x10A5
Parameter setting- Alarm setting
Data Type
Unit
Range
Definition
Authority
0x10A5
4261
PFC_ALARM_SET_MAX_FLOW_RATE-High
FLOAT64
m
3
/s
+0.0000 ~ Line
size(m)^2 *7.85
Max. flow rate
Read /Write
0x10A6
4262
PFC_ALARM_SET_MAX_FLOW_RATE+1
Read /Write
0x10A7
4263
PFC_ALARM_SET_MAX_FLOW_RATE+2
Read /Write
0x10A8
4264
PFC_ALARM_SET_MAX_FLOW_RATE-Low
Read /Write
0x10A9
4265
PFC_ALARM_SET_MIN_FLOW_RATE-High
FLOAT64
m
3
/s
+0.0000 ~ Line
size(m)^2 *7.85
Min. flow rate
Read /Write
0x10AA
4266
PFC_ALARM_SET_MIN_FLOW_RATE+1
Read /Write
0x10AB
4267
PFC_ALARM_SET_MIN_FLOW_RATE+2
Read /Write
0x10AC
4268
PFC_ALARM_SET_MIN_FLOW_RATE-Low
Read /Write
0x10AD
4269
PFC_ALARM_SET_EMPTY_TUBE_DETECT
UINT16
N/A
0: Off
1: On
Empty pipe detection
Read /Write
0x10AE
4270
PFC_ALARM_SET_ALARM_1_FUNC
UINT16
N/A
0: None
1: Max. flow rate
2: Min. flow rate
3: Empty alarm
4: System error
Output 1 contact function
Read /Write
0x10AF
4271
PFC_ALARM_SET_ALARM_1_TYPE
UINT16
N/A
0:NO
1:NC
Output1 contact form
Read /Write
0x10B0
4272
PFC_ALARM_SET_ALARM_2_FUNC
UINT16
N/A
0: None
1: Max. flow rate
2: Min. flow rate
3: Empty alarm
4: System error
Output 2 contact function
Read /Write
0x10B1
4273
PFC_ALARM_SET_ALARM_2_TYPE
UINT16
N/A
0:NO
1:NC
Output2 contact form
Read /Write
0x10B2
4274
PFC_ALARM_SET_CURR_FUNC
UINT16
N/A
0: none
1: Empty alarm
2: System error
Alarm current function
Read /Write
0x10B3
4275
PFC_ALARM_SET_ALARM_CURR_VAL
UINT16
mA
0:3.6
1:3.8
2:20.5
3:22
Alarm current setting
Read /Write
