INTRODUCTION
DieselFirePumpcontrollersaredesignedtostartadieselenginedrivenfirepump.Itcaneither
startthefirepumpmanuallythroughthelocalstartpushbuttonorautomaticallythroughthesens-
ingofapressuredropinthesprinklersystem.Thefirepumpcontrollerissuppliedwithapressure
transducer.Thefirepumpcanbestoppedmanuallywiththelocalstoppushbuttonorauto-
maticallyaftertheexpirationofafieldprogrammabletimer.
TheDieselFirePumpcontroller'smainelectricalsupplyistwosetsofenginebatteries.Addi-
tionally,twobatterychargersconnectedtotheACsupplyvoltagekeepthebatterieschargedatall
times.
Technical Data
Rating Value
RatedOperationalVoltageUe Accordingtothecontrollerratinglabel
RatedOperationalFrequency 50/60Hz
Standardenvironmentaltemperature 4°Cto40°C
Altitude ≤2000m
Relativehumidity 5%to80%
Pollutiondegree 3
Standarddegreeofprotection NEMAType2
Standbypowerconsumption N/A

Energy consumption
Model State 120 VAC 220/240 VAC Output voltage
12VDC Nocharge <0.5A <0.5A 13.8VDC
Fullcharge 6A 4A
24VDC Nocharge <0.5A <0.5A 27.6VDC
Fullcharge 9A 6A
